University of Central Florida Patents Liquid Zoom Lenses for Digital Cameras
As a Florida Patent Attorney, I have a number of friends (and a sister) that went to the University of Central Florida and find patenting news relating to the school of special interest.
As recently reported, the University of Central Florida patents specially designed zoom lenses for digital cameras that replicate the working of the human eye according to UCF News and Information.
At least five Florida patents filed by Florida patent attorneys for the University, have been granted to the University and the technology is licensed to a manufacturing company, Holochip Corp., based in Alburquerque, New Mexico.
The complete article is available here and reproduced below in the event that the link changes or is broken:
The University of Central Florida has signed a licensing agreement with Holochip Corp. for a portfolio of technologies that will allow zoom lenses, such as those used in digital cameras and camera phones, to be manufactured at a dramatically smaller size without compromising clarity.
Shin-Tson Wu, provost-distinguished professor of optics, and his research team at UCF’s College of Optics and Photonics, have developed and patented technologies in the field of adaptive lenses, some of which closely replicate the working of the human eye.
Holochip Corp., based in Albuquerque N.M. and San Francisco, supplies such specialized lenses to manufacturers of camera phones, digital still cameras, medical and military equipment and other products. Under the agreement with the UCF Research Foundation, Holochip gains exclusive worldwide rights to Wu’s adaptive lens patents, including five U.S. patents and numerous foreign applications.
Conventional zoom lenses rely on mechanically moving groups of glass or plastic lenses in order to adjust focus, magnification and field of view. Adaptive lenses, however, offer the ability to change focal lengths while eliminating the need to mechanically change the location of the lens. And it is all done in miniature. The typical aperture size for a lens in a cell phone, for example, is one to two millimeters in diameter.
“We have the ability to make these lenses from less than a millimeter to a couple of centimeters in size,” Wu said.
Wu, who joined UCF in 2001 after 18 years at Hughes Research Laboratories, is known for his advances in the fields of liquid crystal displays (LCDs) and liquid-crystal (LC) optics.
Wu was one of the first researchers to recognize the need for adaptive lenses, and he has directed research that resulted in two distinct approaches. The first, LC lenses, is based on the ability of liquid-crystal materials to alter their refractive index in the presence of an external electric field. With the appropriate selection of LC materials, substrates and device architecture, lenses can be created that adjust their focal length upon an applied voltage.
The second approach, fluidic lenses, was inspired by principles of the human eye. The lens comprises a transparent optical fluid that is encapsulated within a flexible lens membrane and substrate. Upon compression of the lens body, the shape of the flexible lens membrane is modified, which results in an adjustment of the focal length of the lens.
Since this approach provides a wide range of focal power with almost no optical loss, it can be implemented in compact camera modules, making it attractive for size-limited applications such as digital cameras and cell phones. Likewise, the LC lens offers the ability to control high-order aberrations that can lead to blurriness, making it attractive in applications such as free-space optical communications, adaptive optics, corrective eyewear and cameras.
"This technology represents years of effort from Professor Wu and his research group at UCF," said Joe Giampapa, UCF’s tech transfer director. "We are very pleased to take the science to the next level in the commercial development by partnering with Holochip. We believe that Professor Wu’s research, together with Holochip’s aggressive commercialization strategy and manufacturing capabilities, has the potential to create a major impact on camera phones and numerous other optical products and industries."
"With the explosive growth of mobile imaging, and camera phone sales approaching one billion units worldwide, there is a critical need for high-quality, inexpensive and environmentally responsible adaptive lens solutions," said Robert Batchko, CEO of Holochip Corp. "With this agreement and our relationship with Professor Wu and his team, Holochip has taken a significant step toward meeting this need."
Holochip Corp., a manufacturer of adaptive lenses, recently announced its flagship product, an adaptive polymer singlet lens, at the Conference on Lasers and Electro-optics (CLEO-2007) in Baltimore, Md. The company is privately held and was founded in 2004 with financial backing from ITU Ventures, the New Mexico Angels and others. For more information, go to http://www.holochip.com.
